Optical Products / DVD Duplicators

1 to 7 DVD CD Duplicator

MPN: PIO-S7T-DVD-BK

The PioData CD DVD Copier is a standalone SATA CD DVD duplicator. The PioData series is a popular series in Japan and now available globally. The easy to operate control panel and intuitive features make the system perfect for nearly anyone. These units are truly strong performing systems at a more affordable price point to meet the users growing demands without exceeding their budget. The PioData duplicators provide top quality and reliability. Whether you are buying a duplicator for the first time or you are an experienced user, the PioData series of duplicators will grow with your needs and experience.

Key Features:

  1. Complete Standalone Operation:
    No PC required to operate the duplicator.
  2. FREE Copy Protection:
    Able to create FREE copy protected DVD Video copies using OptoDisc MID media from an original master.
  3. Auto DVD Format Conversion:
    Can convert media between DVD+R/RW and DVD-R/RW automatically.
  4. Supports all common CD Formats with Additional Special format including CD-TEXT, ISRC, Over-Burned CD.
  5. Drive firmware upgradeability:
    Capable of upgrading the drives for selected brands through the Duplicator.

Additional Features:

  1. New Supports all common CD Formats with Additional Special format including CD-TEXT, ISRC, Over-Burned CD.
  2. AutoCopy feature:
    Fast duplication without pressing any buttons.
  3. Account management (password protection):
    This function will authorize only specific user(s) to operate the duplicator with their preferred settings. Able to assign numerous passwords for multiple users.
  4. Auto-Counter Technology:
    Displays the total number of discs successfully copied compared to desired output for each project.
  5. User friendly interface with 'easy-to-read' LCD display:
    Offers easy to recognize and use terms and operations on the LCD display for simple usage.
  6. Power on Self diagnostics:
    Keeps the duplicator functioning optimally.
  7. Disc Info feature:
    Provides the format of the disc & the disc manufacturer's information.
  8. Selectable Disc burning speeds:
    Ability to increase or decrease duplication speed for supported formats.
  9. Creates mix compilation audio CD:
    Able to compile multiple tracks onto a single disc from multiple sources.
  10. Supports all currently available DVD media including Double/Dual layer DVD9:
    Can duplicate Single Layer DVD±R/RW and Double/Dual Layer DVD±R Formats.
  11. Automatic format recognition:
    Duplicator recognizes automatically if the discs are CD or DVD as well as the correct format to copy.
  12. Upgradeable for future drive technology:
    Able to upgrade duplicator for installation of future drives.
  13. Future functions upgradeable through firmware:
    Duplicator able to upgrade future software updates via Firmware.
  14. Continuous copying without waiting for cool down:
    No need to stop the duplicator for fear of overheating.
Model DVD/CD Tower Duplicator
Operating Type Stand-alone
Internal Interface SATA
Target 1 - 11
Language Support English, Spanish, French, Russian, Japanese, and more (Chinese can be ordered on request)
Display 16 x 2 Green LCD
Featuring Reader Vinpower DVD-ROM
Featuring Recorder 24x SATA Drive DVD/CD Writer
Maximum Write Speed DVD-R: 24x
DVD+R: 24x
DVD-R DL: 12x
CD-R: 48x		 DVD-RW:6x
DVD+RW: 8x
DVD+R DL: 12x
CD-RW: 32x
Formats Supported DVD-ROM, DVD-Video, DVD-Audio
DVD-R, DVD-RW, DVD+R, DVD+RW
DVD+R Double Layer, DVD-R Dual Layer
CD-ROM (Mode1 & Mode2)
CD-ROM/XA (Mode2 form1 & form2)
CD-DA, Mixed-Mode		 Video CD, CD-I, Karaoke CD(VCD)
Photo CD (Single & Multi-session)
CD-Extra, HFS, CD-Bridge
ISO9660, CD-R, CD-RW
Business Card CD-R, 3" Mini CD-R
Firmware Upgradeable Yes
Burn Proof Support Yes
Power Supply Input : 90 ~ 240 V, Up to 500 WATT max
Operating Humidity 20% ~ 80%
Temperature Extremes 40°C (104°F) / 5°C (41°F)
Regulations FCC, CE, RoHS
Manufacture Vinpower Digital



Important Notice

  • The duplicator will not copy any copy-protected or encrypted disc(s).
  • The actual maximum writing speed may vary. Blank media writing speed is determined by the drives, regardless of what the media manufacturer certifies the blank media writing speed at.

Throughput Capacity Per Hour:

Target 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
 350 MB CD
 *at 40x duplication speed		 24 48 72 96 120 144 168 192 216 240 264 288 312 336 360
 2.5 GB DVD
 *at 16x duplication speed 		12 24 36 48 60 72 84 96 108 120 132 144 156 168 180

PIODATA has developed the first true standalone duplicator which can offer embedded copy protection. The unique CopyLock Software can embed a proprietary CPS copy protection encryption into any DVD video master through a PC, which will produce a VCP or FREE OCP protected image file. The VCP or FREE OCP protected image file can then be burned onto a master disc and used in a CPS enabled Vinpower Digital duplicator to produce as many copy protected reproductions as the user needs. Since the CPS technology is software based as opposed to hardware based, there are no issues with compatibility with players, unlike competing protections on the market. In addition, the CPS technology offers the same secure protection against unauthorized duplication and ripping for a double dose of protection whereas similar applications from competitors cannot block ripping.

The difference between the VCP and FREE OCP formats is that the VCP requires a license dongle in order to add the protection onto both 4.7GB SL DVD and 8.5GB DL DVD discs and the FREE OCP does not require any licenses as long as true OptoDisc MID media are used during the duplication process and it can only be used on 4.7GB SL DVD. The added cost for the VCP allows you to use any media you’d like and works on DVD+R DL media, while the OCP has no added costs as long as you use OptoDisc manufactured media.
In today’s savvy hi-tech world, consumers are often purchasing a single video and making copies for their friends which limit the overall sales. If you worked hard and put in a lot of effort and expense into creating your video project, you shouldn’t be restricted in the number of units you can sell because you can't afford the high price of replicated copy protection. Instead, by using Vinpower Digital's CPS technology, you can feel secure at a fraction of the expense with the VCP format or FREE with the OCP format in less time with no minimum or maximum quantities required.

Flow Chart



How the FREE OCP Copy Protection Works:
2. Load the supplied CopyLock software onto a suitable PC.
2. Take your DVD video master disc or file and use the copy protection software application to make an OCP master image file; follow the steps of the software to embed the copy protection onto the master content.
3. Burn the OCP file onto a master disc and use that new protected file as your master source
4.  into the duplicator’s writer drive(s) then place the OCP master disc into the top reader tray or locate the transferred OCP image file through the duplicator’s menu keys from the internal hard drive if available
5. Initiate the copy process and when the finished discs are all successfully copied, these discs will have the secure copy protection already embedded.

How the VCP Format Copy Protection Works:
1. Load the supplied CopyLock software onto a suitable PC.
2. Plug in the CPS USB dongle with activated licenses into your PC's USB socket.
3. Take your DVD video master disc or file and by utilizing the special CPS application, follow the steps to embed the copy protection onto the master content.
4. Burn the VCP file onto a master disc and use that new protected file as your master source
5. Load blank DVD recordable discs into the duplicator's writer drive(s) then then place the VCP master disc into the top reader tray or locate the transferred VCP image file through the duplicator's menu keys from the internal hard drive if available
6. Initiate the copy process and when the finished discs are all successfully copied, these discs will have the secure copy protection already embedded.
